Anti-interference RJ45 Cable
10G RJ45 Field Plug Pro – Angled 360°
Available in 360° angled versions, with 4-pair and 2-pair options, it can be quickly assembled on-site without special tools. Its compact design is suitable for confined spaces and multi-port installations.
With a robust zinc die-cast housing, protected latch, and full shielding, it is ideal for industrial use. It also supports PoE, PoE+, UPoE, 4PPoE, HDBaseT, PROFINET, and EtherNet/IP applications.
- Full Detail
- Specifications
- Features List
- Applications / Use Cases
- Download Brochure
10G RJ45 Field Plug Pro – Angled 360°
Specifications
Features List
Cat.6A class EA RJ45 plug to be assembled in the field
fully shielded and multi-port capable
variable (360°) cable feed, freely selectable
easy assembly - connection without special tools
wire connection: stranded wire AWG 27/7 to 22/7, wire diameter from 0.46 to 0.76 mm
wire connection: solid wire AWG 26/1 to 22/1, wire diameter from 0.409 to 0.64 mm
transmission characteristics Cat.6A according to ISO/IEC 11801
compliance with class EA according to ISO/IEC 11801, DIN EN 50173-1
degree of protection IP20
for cable jacket from 5.50 to 9.50 mm
zinc die-cast housing for industrial use
strain relief by latching clip directly on the stuffer cap
protected locking hook
reconnectable
Applications / Use Cases
Core Application Fields
Structured Building Cabling (Office & Residential Buildings)
Industrial Communication Networks (Industrial Premises & Factories)
Data Centers & Server Rooms
Distributed Building Services / Building Automation
Specific Target Applications & Technologies
10 Gigabit Ethernet (10GBASE-T / IEEE 802.3an)
Remote Powering (Power over Ethernet - PoE, PoE+, 4PPoE / IEEE 802.3af)
PROFINET Applications (Category 5/6A industrial Ethernet networks)
HDBaseT Deployments (High-definition video and data transmission)
Field-Terminated Connections (Quick assembly on-site without special tools)
Environmental & Mechanical Adaptability (MICE Ratings)
Mechanical rating: M1
Ingress rating: I1
Climatic rating: C1
Electromagnetic rating: E2
